Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [23.02.2023] Märkische Stanz-Partner Neue Normteile für Stanzerei-Großwerkzeuge New Standard Components for Large Stamping and Forming Dies Stand / Revision Status 23.02.2023

[2] Märkische Stanz-Partner STANZNORMALIEN / STANDARD DIE COMPONENTS 02] [03.12.2018] Wegweiser Guide Ein „Klick“ auf Artikelbezeichnung, Bestell-Nummer oder Seite im vorangestellten Inhaltsverzeichnis bringt Sie zum gewünschten Artikel. Ein „Klick“ auf Foto, Artikelbezeichnung, Bestell-Nummer oder Seite im Inhaltsverzeichnis des Registers bringt Sie unmittelbar zum gewünschten Artikel im Katalog. Ein „Klick“ auf das CAD-Logo bringt Sie zu den CADDaten des gewünschten Artikels im CADENASDownloadportal. Ein „Klick“ auf das RETURN-Logo unten auf jeder Katalogseite bringt Sie zurück auf das Inhaltsverzeichnis des entsprechenden Registers. „Clicking“ on the RETURN-logo at the bottom of each catalog-page opens that specific register‘s table of contents. Ein „Klick“ auf das MAIL-Logo generiert eine an die Märkischen Stanz-Partner adressierte e-mail, mit der Normbezeichnung des gewünschten Artikels in der Betreffzeile. „Clicking“ on the MAIL-logo generates an e-mail addressed to the Stanz-Partners, showing the requested article in the subject heading. „Clicking“ on the CAD-logo leads you to the CAD-file(s) of the corresponding article within the Cadenas download-portal. „Clicking“ on the Article name, the Order- or Page-no. in the main table of contents opens the corresponding article-page. „Clicking“ on the Photo, the Article name, the Order- or Page-no. in any register‘s table of contents opens the corresponding article-page. CAD CAD MAIL MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [3] [23.02.2023] Inhalt Content Führungselemente Guiding elements Best.-Nr. Order no. Seite Page Führungssäulen für Großwerkzeuge, DIN 9833 Leader pins for large dies, DIN 9833 FS 410 [7] Führungssäulen für Großwerkzeuge, DIN 9833 Leader pins for large dies, DIN 9833 FS 412 [8] Führungsbuchsen mit Bund mit Festschmierstoff, DIN 9834 / ISO 9448 Leader pin bushings with collar with self lubricating graphite plugs, DIN 9834 / ISO 9448 FS 460 [9] Führungsbuchsen mit Bund mit Festschmierstoff, NAAMS Leader pin bushings with collar with self lubricating graphite plugs, NAAMS FS 461 [10] Führungsbuchsen ohne Bund mit Festschmierstoff Leader pin bushings without collar with self lubricating graphite plugs FS 462 [11] Gleitplatten, VDI 3357, Bronze mit Festschmierstoff, 20 mm dick Wear plates, VDI 3357, bronze with self lubricating graphite plugs, 20 mm thick FS 500 [12] Gleitplatten, VDI 3357, Stahl, 20 mm dick Wear plates, VDI 3357, steel, 20 mm thick FS 501 [13] Gleitplatten, VDI 3357, Bronze mit Festschmierstoff, 12 mm dick Wear plates, VDI 3357, bronze with self lubricating graphite plugs, 12 mm thick FS 502 [14] Gleitplatten, Bronze mit Festschmierstoff, 10 mm dick Wear plates, bronze with self lubricating graphite plugs, 10 mm thick FS 503 [15] Gleitplatten, Bronze mit Festschmierstoff, 10 mm dick Wear plates, bronze with self lubricating graphite plugs, 10 mm thick FS 504 [16] Gleitplatten, Bronze mit Festschmierstoff, 5 mm dick Wear plates, bronze with self lubricating graphite plugs, 5 mm thick FS 505 [17] Gleitleisten, VDI 3357, Bronze mit Festschmierstoff Wear strips, VDI 3357, bronze with self lubricating graphite plugs FS 506 [18] Überlaufkeile, VDI 3357, Bronze mit Festschmierstoff Cam dwells, VDI 3357, bronze with self lubricating graphite plugs FS 507 [19] Überlaufkeile, VDI 3357, Stahl Cam dwells, VDI 3357, steel FS 508 [20] Führungslaschen, Stahl mit Festschmierstoff Guide brackets, steel with self lubricating graphite plugs FS 509 [21] Winkelleisten, Bronze mit Festschmierstoff „L“ shaped wear plates, bronze with self lubricating graphite plugs FS 510 [22] Winkelleisten, VDI 3357, Bronze mit Festschmierstoff „L“ shaped wear plates, VDI 3357, bronze with self lubricating graphite plugs FS 511 [23] Prismenführungen, VDI 3357, Stahl „V“ drivers, VDI 3357, steel FS 524 [24] Prismenführungen, VDI 3357, Bronze mit Festschmierstoff „V“ drivers, VDI 3357, bronze with self lubricating graphite plugs FS 526 [25] Haltestücke für Führungsbuchsen mit Festschmierstoff n.DIN 9834 / ISO 9448 Holding clamps for bronze leader pin bushings with selflubricating graphite plugs, DIN 9834 / ISO 9448 FS 460 HS [26]

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [4] [23.02.2023] Inhalt Content Technische Hilfsmittel General die components Best.-Nr. Order no. Seite Page Platinen-Einweiser Pilot gages TH 900 [27] Platinen-Einweiser, induktiv gehärtet Pilot gages, inductively hardened TH 900 … CH [28] Platinen-Einweiser mit Teillagekontrolle, induktiv gehärtet Pilot gages with part position control, inductively hardened TH 901 [29] Lagekontrolle für Platinen Position control for blanks NC.39D 639 [30] Zentriereinheiten mit Distanzscheibe Tapered interlocks with spacer disk TH 920 [31] Zentrierbolzen Locating pins TH 943 TH 944 [32] Tragschrauben, VDI 3366 Lifting pins, VDI 3366 TH 230 [33] Tragzapfen, VDI 3366 Lifting brackets, VDI 3366 TH 220 [34] Tragzapfen mit Seilsicherung, VDI 3366 Lifting brackets with cable rope stop safety, VDI 3366 TH 221 [35] Tragbolzen mit Fallringsicherung, VDI 3366 Lifting pins, VDI 3366 TH 250 [36] Unterluftbolzen Lower air pins TH 908 [37] Unterluftbolzen Lower air pins TH 909 [38] Oberluftbolzen, VDI 3002 Upper air pins, VDI 3002 TH 910 [39] Unterluftbolzen Lower air pins NC.39D 951/21 [40] Steckbolzen, Form 1, VDI 3365 Pad retainer pins, Form 1, VDI 3365 TH 911 [41] Steckbolzen, Form 2, VDI 3365 Pad retainer pins, Form 2, VDI 3365 TH 912 [42] Dämpfungssysteme für Schieber Slider stop damping system NC.39D 630/22 [43] Abstellrohre mit Klappvorrichtung, 5 mm Pipe with assembly, 5 mm NC.39D 578/70 [44] Abstellrohre mit Klappvorrichtung, 3 mm Pipe with assembly, 3 mm NC.39D 578/80 [45] Kennzeichnungsstempel Norm-39V 1079 Identification punches Standard-39V 1079 TH 39V 1079 [47]

[23.03.2023] AZOL GAS Gasdruckfedern AZOL GAS Gas springs Best.-Nr. Order no. Seite Page Pneumatik-Federn, Serie AZ-VW 110 80 - 200 daN. Hub 12.7 - 160 mm, Ø 95 - 230 mm Pneumatic springs, AZ-VW 110 series, 80 - 200 daN. Stroke 12.7 - 160 mm, Ø 95 - 230 mm AZ-VW 110 [52] - [61] Gasdruckfedern, Teileheber Gas springs, Strippers EXU EXY [62] [63] Abdrückstifte mit Stahlfeder 9 - 89 N, Hub 20 - 50 mm, Ø M16x1,5 Plungers with steel spring 9 - 89 N, Stroke 20 - 50 mm, Ø M16x1,5 MBFP 16 [64] Technische Hilfsmittel General die components Best.-Nr. Order no. Seite Page Aufnahmen für Kennzeichnungsstempel Norm-39D 647 Retainers for identification punches Standard-39D 647 TH 39D 647 [48] [49] Prägewerke Norm-39D 991 A, Norm-39D 991 B Numbering heads Standard-39D 991 A, Standard-39D 991 B TH 39D 991 A TH 39D 991 B [50] [51] Prägewerk-Ringe für TH 39D 991 B Numbering head rings for TH 39D 991 B TH 927 [51] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [5] Inhalt Content

[23.02.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [6] Notizen Notes

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [7] [23.02.2023] Führungssäulen für Großwerkzeuge, DIN 9833 Leader pins for large dies, DIN 9833 Mat.: steel Surface hardness: 60 - 64 HRC Hardening depth: 1,5 + 1 mm Mat.: Stahl Oberflächenhärte: 60 - 64 HRC Einhärtungstiefe: 1,5 + 1 mm ✎FS 410 / 50 x 200 d1 l1-1 l2 l3 l4 d2 r1 r2 f6 125 140 160 180 200 224 250 280 315 355 400 450 +0,8 +0,8 +0,8 r6 25 l l l l l l 8 4 40 25 3 2 32 l l l l l l 8 4 45 32 3 2 40 l l l l l l l 8 4 56 40 3 2 50 l l l l l l l l 10 4 7050 52,5 63 l l l l l l l l 10 4 8063 62,5 80 l l l l l l l l 10 4 10080 8 3 100 l l l l l l l 10 4 125 100 10 3 FS 410 FS 410 FS 460 HS M12 (nur für/only for d1=80, d1=100) FS 460 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [8] [23.02.2023] Führungssäulen für Großwerkzeuge, DIN 9833 Leader pins for large dies, DIN 9833 Mat.: steel Surface hardness: 60 - 64 HRC Hardening depth: 1,5 + 1 mm Mat.: Stahl Oberflächenhärte: 60 - 64 HRC Einhärtungstiefe: 1,5 + 1 mm ✎FS 412 / 50 x 200 d1 l1 l2 l3 l4 d2 d3 d4 r1 r2 f6 200 224 250 280 315 355 400 450 500 560 +0,8 +0,8 +0,8 r6 ±2 +0,8 80 l l l l l l l l 10 4 10080 40 58 8 3 100 l l l l l l l 10 4 125 100 50 72 10 3 125 l l l l l 12 4 140 125 65 90 12 4 160 l l l l 12 5 180 160 95 132 18 4 FS 412 FS 412 FS 460 HS FS 460 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [9] [23.02.2023] Führungsb. mit Festschmierstoff, DIN 9834 / ISO 9448 Leader pin bushings with self lubricating graphite plugs ✎FS 460 / 40 FS 460 FS 460 HS . FS 460 with collar Mat.: Bronze-graphite Holding clamps need to be ordered separately! mit Bund Mat.: Bronze-Graphit Haltestücke bitte gesondert bestellen! d1 H7 d2 h6 d3 -0,25 d4 -0,8 d6 ±0,3 l1 -0,5/-1 l3 ±0,1 l4 ±1 l5 -0,5 r1 Haltestück Typ Holding clamps type 25 32 32 40 58 40 6,3 3 10 3 FS 460 HS 1 32 40 40 50 66 50 6,3 4 12 3 FS 460 HS 1 40 50 50 63 79 63 6,3 5 15 3 FS 460 HS 1 50 63 63 71 89 71 6,3 6,3 17 5 FS 460 HS 1 63 80 80 90 123 80 10 8 19 6 FS 460 HS 2 80 100 100 112 143 100 10 10 22 8 FS 460 HS 2 100 125 125 140 168 125 10 12,5 21 10 FS 460 HS 2 125 160 160 180 203 160 10 16 30 12 FS 460 HS 2 160 200 200 220 243 200 10 16 32 18 FS 460 HS 2 Detail X MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [10] [23.02.2023] Führungsbuchsen mit Festschmierstoff, NAAMS Leader pin bushings with self lubricating graphite plugs, NAAMS ✎FS 461 / 40 FS 461 FS 460 HS 3 FS 461 with collar Mat.: Bronze-graphite Holding clamps need to be ordered separately! mit Bund Mat.: Bronze-Graphit Haltestücke bitte gesondert bestellen! d1 H7 d2 g6 d3 -0,25 d4 -0,8 d6 ±0,3 l1 -0,5 l2 l4 r1 Haltestück Typ Holding clamps type 25 32 32 40 75 40 30 4 3 FS 460 HS 3 32 40 40 50 83 50 40 4 3 FS 460 HS 3 40 50 50 63 93 63 50 5 3 FS 460 HS 3 50 63 63 71 106 71 56 6 5 FS 460 HS 3 63 80 80 90 123 80 63 8 6 FS 460 HS 3 80 100 100 112 143 100 80 10 8 FS 460 HS 3 100 125 125 140 168 125 106 12 10 FS 460 HS 3 125 160 160 180 203 160 132 12 12 FS 460 HS 3 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [11] [23.02.2023] Führungsbuchsen mit Festschmierstoff Leader pin bushings with self lubricating graphite plugs without collar Mat.: Bronze-graphite ohne Bund Mat.: Bronze-Graphit ✎FS 462 / 20 x 28 x 30 FS 462 d d1 l -0,1/-0,3 l2 F7 m6 8 10 12 15 16 20 25 30 35 40 50 60 70 80 100 120 8 12 l l l l 2 10 14 l l l l 2 12 18 l l l l l l 2 16 22 l l l l l l l 2 18 24 l l l l l 2 20 28 l l l l l 2 20 30 l l l l l l 2 25 33 l l l l l l 2 25 35 l l l l l l 2 30 38 l l l l l l 2 30 40 l l l l l l 2 35 44 l l 2 35 45 l l l l 2 40 50 l l l l l l 2 40 55 l l 2 50 60 l l l 2 50 62 l l 2 50 65 l l 2 60 75 l l l 2 70 85 l l l l 2 80 96 l l 2 80 100 l l l 2 100 120 l 2 110 130 l l 2 130 150 l 4 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [12] [23.02.2023] Gleitplatten VDI 3357, Bronze mit Festschmierstoff, 20 mm dick Wear plates VDI 3357, bronze with self lubricating graphite plugs, 20 mm thick Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 500 / 80 x 250 FS 500 b1 l1 Form b2 d1 d2 l2 l3 t 50 80 B - 15 9 55 25 9 50 100 B - 20 13,5 75 25 13 50 125 B - 20 13,5 100 25 13 50 160 B - 20 13,5 135 25 13 50 200 B - 20 13,5 175 25 13 80 50 A 30 15 9 - 25 9 80 80 B - 20 13,5 55 25 13 80 100 B - 20 13,5 75 25 13 80 125 B - 20 13,5 100 25 13 80 160 B - 20 13,5 135 25 13 80 200 B - 20 13,5 175 25 13 80 250 B - 20 13,5 210 40 13 80 315 B - 20 13,5 275 40 13 100 50 A 50 20 13,5 - 25 13 100 80 A 50 20 13,5 - 40 13 100 100 B - 20 13,5 75 25 13 100 125 B - 20 13,5 100 25 13 100 160 B - 20 13,5 135 25 13 100 200 B - 20 13,5 175 25 13 b1 l1 Form b2 d1 d2 l2 l3 t 100 250 B - 20 13,5 210 40 13 100 315 B - 20 13,5 275 40 13 125 50 A 75 20 13,5 - 25 13 125 80 A 75 20 13,5 - 40 13 125 100 C 75 20 13,5 75 25 13 125 125 C 75 20 13,5 100 25 13 125 160 C 75 20 13,5 135 25 13 125 200 C 75 20 13,5 175 25 13 125 250 C 75 20 13,5 210 40 13 125 315 C 75 20 13,5 275 40 13 160 50 A 110 20 13,5 - 25 13 160 80 A 110 20 13,5 - 40 13 160 100 C 110 20 13,5 75 25 13 160 125 C 110 20 13,5 100 25 13 160 160 C 110 20 13,5 135 25 13 160 200 C 110 20 13,5 175 25 13 160 250 D 110 20 13,5 210 40 13 160 315 D 110 20 13,5 275 40 13 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [13] [23.02.2023] b1 l1 Form b2 d1 d2 l2 l3 t 50 80 B - 15 9 55 25 9 50 100 B - 20 13,5 75 25 13 50 125 B - 20 13,5 100 25 13 50 160 B - 20 13,5 135 25 13 50 200 B - 20 13,5 175 25 13 80 50 A 30 15 9 - 25 9 80 80 B - 20 13,5 55 25 13 80 100 B - 20 13,5 75 25 13 80 125 B - 20 13,5 100 25 13 80 160 B - 20 13,5 135 25 13 80 200 B - 20 13,5 175 25 13 80 250 B - 20 13,5 210 40 13 80 315 B - 20 13,5 275 40 13 100 50 A 50 20 13,5 - 25 13 100 80 A 50 20 13,5 - 40 13 100 100 B - 20 13,5 75 25 13 100 125 B - 20 13,5 100 25 13 100 160 B - 20 13,5 135 25 13 100 200 B - 20 13,5 175 25 13 b1 l1 Form b2 d1 d2 l2 l3 t 100 250 B - 20 13,5 210 40 13 100 315 B - 20 13,5 275 40 13 125 50 A 75 20 13,5 - 25 13 125 80 A 75 20 13,5 - 40 13 125 100 C 75 20 13,5 75 25 13 125 125 C 75 20 13,5 100 25 13 125 160 C 75 20 13,5 135 25 13 125 200 C 75 20 13,5 175 25 13 125 250 C 75 20 13,5 210 40 13 125 315 C 75 20 13,5 275 40 13 160 50 A 110 20 13,5 - 25 13 160 80 A 110 20 13,5 - 40 13 160 100 C 110 20 13,5 75 25 13 160 125 C 110 20 13,5 100 25 13 160 160 C 110 20 13,5 135 25 13 160 200 C 110 20 13,5 175 25 13 160 250 D 110 20 13,5 210 40 13 160 315 D 110 20 13,5 275 40 13 Gleitplatten VDI 3357, Stahl, 20 mm dick Wear plates VDI 3357, steel, 20 mm thick Mat.: 16MnCr5 Surface hardness: 60 - 64 HRC Mat.: 16MnCr5 Oberflächenhärte: 60 - 64 HRC ✎FS 501 / 80 x 50 FS 501 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [14] [23.02.2023] Gleitplatten VDI 3357, Bronze mit Festschmierstoff, 12 mm dick Wear plates VDI 3357, bronze with self lubricating graphite plugs, 12 mm thick Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 502 / 30 x 100 FS 502 b1 l1 l2 30 80 55 30 100 75 30 125 100 30 160 135 30 200 175 40 80 55 40 100 75 40 125 100 40 160 135 40 200 175 50 80 55 50 100 75 50 125 100 b1 l1 l2 50 160 135 50 200 175 60 80 55 60 100 75 60 125 100 60 160 135 60 200 175 80 80 55 80 100 75 80 125 100 80 160 135 80 200 175 9 15 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [15] [23.02.2023] Gleitplatten, Bronze mit Festschmierstoff, 10 mm dick Wear plates, bronze with self lubricating graphite plugs, 10 mm thick Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 503 / 18 x 125 FS 503 a l l1 l2 18 75 15 45 18 100 25 50 18 125 25 75 18 150 25 100 28 75 15 45 28 100 25 50 28 125 25 75 28 150 25 100 38 75 15 45 38 100 25 50 38 125 25 75 38 150 25 100 48 75 15 45 48 100 25 50 48 125 25 75 48 150 25 100 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [16] [23.02.2023] Gleitplatten, Bronze mit Festschmierstoff, 10 mm dick Wear plates, bronze with self lubricating graphite plugs, 10 mm thick Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 504 / 48 x 150 FS 504 a l Form b l1 l2 28 75 A - 15 45 28 100 A - 25 50 28 125 A - 25 75 28 150 A - 25 100 38 75 A - 15 45 38 100 A - 25 50 38 125 A - 25 75 38 150 A - 25 100 48 75 A - 15 45 48 100 A - 25 50 48 125 A - 25 75 48 150 A - 25 100 48 200 A - 50 100 58 75 A - 15 45 58 100 A - 25 50 58 125 A - 25 75 58 150 A - 25 100 a l Form b l1 l2 58 200 A - 50 100 75 75 A - 15 45 75 100 A - 25 50 75 125 A - 25 75 75 150 A - 25 100 75 200 C - 25 75 100 100 B 50 25 50 100 125 B 50 25 75 100 150 B 50 25 100 100 200 B 50 25 150 100 250 B 50 25 200 125 150 B 50 25 100 125 200 B 50 25 150 125 250 B 50 25 200 150 150 B 100 25 100 150 200 B 100 25 150 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [17] [23.02.2023] Gleitplatten, Bronze mit Festschmierstoff, 5 mm dick Wear plates, bronze with self lubricating graphite plugs, 5 mm thick Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 505 / 75 x 75 FS 505 a l Form b d l1 18 50 A - 6,5 20 18 75 A - 6,5 45 18 100 A - 6,5 70 18 150 B - 6,5 60 28 50 A - 9 20 28 75 A - 9 45 28 100 A - 9 70 28 150 B - 9 60 38 50 A - 9 20 38 75 A - 9 45 38 100 A - 9 70 38 150 B - 9 60 48 75 A - 9 45 48 100 A - 9 70 48 125 A - 9 95 48 150 B - 9 60 75 75 C 45 9 45 75 100 C 45 9 70 75 125 C 45 9 95 75 150 D 45 9 60 100 100 C 70 9 70 100 125 C 70 9 95 100 150 D 70 9 60 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [18] [23.02.2023] Gleitleisten VDI 3357, Bronze mit Festschmierstoff Wear strips VDI 3357, bronze with self lubricating graphite plugs with 2 slide surfaces Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. mit 2 Gleitflächen Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 506 / 15 x 110 FS 506 h -0,02 l1 H7 Form b1 -0,02 b2 d1 H13 d2 H13 l2 l3 ±0,2 l4 ±0,2 t +0,5 12 110 A 25 12,5 9 15 25 85 - 8,5 12 120 A 25 12,5 9 15 25 95 - 8,5 15 110 A 25 12,5 11 18 25 85 - 10,5 15 120 A 25 12,5 11 18 25 95 - 10,5 30 125 A 60 30 13,5 20 25 100 - 13 30 160 A 60 30 13,5 20 25 135 - 13 30 200 B 60 30 13,5 20 25 100 175 13 40 125 A 60 30 13,5 20 25 100 - 13 40 160 A 60 30 13,5 20 25 135 - 13 40 200 B 60 30 13,5 20 25 100 175 13 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [19] [23.02.2023] Überlaufkeil VDI 3357, Bronze mit Festschmierstoff Cam dwells VDI 3357, bronze with self lubricating graphite plugs with 2 slide surfaces Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. mit 2 Gleitflächen Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 507 / 125 x 170 x 45 FS 507 b l t ±0,1 a l1 ±0,5 w 100 170 45 60 143,37 20° 125 170 45 85 143,37 20° 150 170 45 110 143,37 20° 100 150 45 60 127,86 30° 100 170 60 60 127,86 30° 125 150 45 85 127,86 30° 125 170 60 85 127,86 30° 150 150 45 110 127,86 30° 150 170 60 110 127,86 30° MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [20] [23.02.2023] Überlaufkeile VDI 3357, Stahl Cam dwells VDI 3357, steel Mat.: X153CrMoV12 Surface hardness: 60 - 62 HRC Mat.: X153CrMoV12 Oberflächenhärte: 60 - 62 HRC ✎FS 508 / 125 x 170 x 45 FS 508 b l t ±0,1 a l1 ±0,5 w 100 170 45 60 143,37 20° 125 170 45 85 143,37 20° 150 170 45 110 143,37 20° 100 150 45 60 127,86 30° 100 170 60 60 127,86 30° 125 150 45 85 127,86 30° 125 170 60 85 127,86 30° 150 150 45 110 127,86 30° 150 170 60 110 127,86 30° MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [21] [23.02.2023] Führungslaschen, Stahl mit Festschmierstoff Guide brackets, steel with self lubricating graphite plugs Mat.: CK45 Surface hardness: 58 - 60 HRC Mat.: CK45 Oberflächenhärte: 58 - 60 HRC ✎FS 509 / 63 x 180 x 36 FS 509 a l1 b l2 l3 e1 e2 d1 d2 t f r Form 63 180 36 90 20 50 50 14 20 16 18 16 A 63 200 36 90 20 50 50 14 20 16 18 16 A 63 224 36 90 20 50 50 14 20 16 18 16 A 71 180 36 90 20 50 50 14 20 16 18 16 A 71 200 36 90 20 50 50 14 20 16 18 16 A 71 224 36 90 20 50 50 14 20 16 18 16 A 90 200 36 100 20 50 50 18 26 21 28 25 A 90 224 36 100 20 50 50 18 26 21 28 25 A 90 250 36 100 20 50 50 18 26 21 28 25 A 90 200 45 100 20 50 50 18 26 21 28 25 A 90 224 45 100 20 50 50 18 26 21 28 25 A 90 250 45 100 20 50 50 18 26 21 28 25 A 112 200 45 100 20 50 50 18 26 21 28 25 A 112 224 45 100 20 50 50 18 26 21 28 25 A 112 250 45 100 20 50 50 18 26 21 28 25 A 140 315 45 150 40 90 80 22 33 25,5 36 31,5 B 140 400 45 150 40 90 80 22 33 25,5 36 31,5 B 140 315 56 150 40 90 80 22 33 25,5 36 31,5 B 140 400 56 150 40 90 80 22 33 25,5 36 31,5 B 190 315 45 150 40 90 80 22 33 25,5 36 31,5 B 190 400 45 150 40 90 80 22 33 25,5 36 31,5 B 190 315 56 150 40 90 80 22 33 25,5 36 31,5 B 190 400 56 150 40 90 80 22 33 25,5 36 31,5 B 240 500 56 250 40 160 160 26 40 30,5 36 31,5 B 240 630 56 250 40 160 160 26 40 30,5 36 31,5 B ≥15 kg e1 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [22] [23.02.2023] Winkelleisten, Bronze mit Festschmierstoff “L” shaped wear plates, bronze with self lubricating graphite plugs Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 510 / 20 x 26 x 100 FS 510 a ±0,25 b ±0,25 l Form l1 l2 l3 l4 l5 l6 Bohrungen Holes 20 26 100 D 20 80 - - - 9 2 20 26 150 D 20 75 130 - - 9 3 20 26 200 D 20 75 125 180 - 9 4 30 32 100 B 20 80 - - - 11 2 30 32 150 B 20 75 130 - - 11 3 30 32 200 B 20 75 125 180 - 11 4 30 32 250 B 20 90 160 230 - 11 4 40 40 160 C 15 145 - - - 12 2 40 40 250 C 15 145 225 - - 12 3 45 50 200 A 20 75 125 180 - 14 4 45 50 250 A 20 90 160 230 - 14 4 45 50 300 A 20 85 150 215 280 14 5 45 50 350 A 20 100 175 250 330 14 5 l6 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [23] [23.02.2023] Winkelleisten, Bronze mit Festschmierstoff, VDI 3357 “L” shaped wear plates, bronze with self lubricating graphite plugs, VDI 3357 Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 511 / 55 x 55 x 100 FS 511 b1 ±0,2 h1 ±0,2 l -0,2 Form b2 -0,02 b3 ±0,2 d H13 l1 ±0,2 l2 ±0,2 l3 ±0,2 l4 ±0,2 l5 ±0,2 h2 +0,02 55 55 100 A 37 20 13,5 27,5 - - - 72,5 39 55 55 160 A 37 20 13,5 27,5 - - - 132,5 39 70 75 160 A 50 30 17,5 35 - - - 125 55 70 75 200 A 50 30 17,5 35 - - - 165 55 70 75 250 B 50 30 17,5 35 - 125 - 215 55 70 75 400 C 50 30 17,5 35 125 200 275 365 55 85 90 160 A 63 38 22 42,5 - - - 117,5 65 85 90 200 A 63 38 22 42,5 - - - 157,5 65 85 90 250 B 63 38 22 42,5 - 125 - 207,5 65 85 90 400 C 63 38 22 42,5 125 200 275 357,5 65 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [24] [23.02.2023] Prismenführungen, Stahl, VDI 3357 “V” Drivers, steel, VDI 3357 Mat.: CK45 Surface hardness: 56 - 60 HRC Mat.: CK45 Oberflächenhärte: 56 - 60 HRC ✎FS 524 / 65 x 150 FS 524 b h6 l1 -0,2 d1 H13 d2 H13 d3 H7 h1 ±0,2 h2 ±0,01 h3 ±0,2 h4 l2 ±0,2 l3 ±0,01 l4 ±0,2 r z +0,05 65 150 13,5 20 12 35 18 22 8 125 45 - 7 65 65 200 13,5 20 12 35 18 22 8 175 95 - 7 65 65 250 13,5 20 12 35 18 22 8 225 145 125 7 65 65 300 13,5 20 12 35 18 22 8 275 195 150 7 65 125 150 17,5 26 16 60 28 34 15 125 45 - 10 85 125 200 17,5 26 16 60 28 34 15 175 95 - 10 85 125 250 17,5 26 16 60 28 34 15 225 145 125 10 85 125 300 17,5 26 16 60 28 34 15 275 195 150 10 85 FS 524 FS 526 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [25] [23.02.2023] Prismenführungen, Bronze mit Festschmierstoff, VDI 3357 “V” Drivers, bronze with self lubricating graphite plugs, VDI 3357 Mat.: Bronze-graphite Bronze wear plates with self lubricating graphite plugs ensure a low maintenance operation, even during long-term production cycles. Mat.: Bronze-Graphit Gleitplatten aus Bronze mit Festschmierstoff-Einsätzen gewährleisten auch im Dauerbetrieb einen wartungsarmen Einsatz. ✎FS 526 / 65 x 150 FS 526 b h6 l1 -0,2 d1 H13 d2 H13 d3 H7 d4 H13 h1 ±0,01 h3 l2 ±0,2 l3 ±0,01 l4 ±0,2 z +0,05 65 150 13,5 20 12 14 47 3 125 45 - 65 65 200 13,5 20 12 14 47 3 175 95 - 65 65 250 13,5 20 12 14 47 3 225 145 125 65 65 300 13,5 20 12 14 47 3 275 195 150 65 125 150 17,5 26 16 18 57 5 125 45 - 85 125 200 17,5 26 16 18 57 5 175 95 - 85 125 250 17,5 26 16 18 57 5 225 145 125 85 125 300 17,5 26 16 18 57 5 275 195 150 85 FS 524 FS 526 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [26] [23.02.2023] Haltestücke Holding clamps for leader pin bushings FS 460 DIN 9834 / ISO 9448 Mat.: CK45 für Führungsbuchse FS 460 nach DIN 9834 / ISO 9448 Mat.: CK45 ✎FS 460 HS 1 FS 460 HS . Typ Type b1 b2 d2 +0,2 d3 +0,2 h l -0,3 t1 t2 t3 Ø Buchse Ø Bushing Schraube Screw HS 1 20 7,5 7 11 10 20 7 6,3 5 25-50 M6x16 HS 2 32 11 11,5 17,5 16 32 11,5 10 10 63-160 M10x20 HS 3 32 11 11,5 17,5 16 32 11,5 6 10 25-160 M10x20 HS 5 21 7,5 6,2 – 11,5 25 – 5,7 ?? 25-50 M6x15 HS 6 32 11 10,2 – 19 40 – 9,3 ?? 63-160 M10x20 d3 t1 h d2 t3 27 t2 +0,2 l b1 b2 l/2 www.gsb-oilless.com info@gsb-oilless.co 2.70 2 Burç Tutuc Clamps for Bushin Haltestüc Material : S235JRH Screw not included. CODE w l d B h Bushes Size Screw A101-06-025021 25 21 6,2 11,5 5,7 Ø25 - Ø50 M6x15 A101-06-040032 40 32 10,2 19 9,3 Ø63 - Ø160 M10x20 B h d w l h t2 d2 l b1 FS 460 HS 1/2 FS 460 HS 3 FS 460 HS 5/6 b2 t3 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [27] [23.02.2023] Platinen-Einweiser, Automobil-Ausführung Pilot gages, automotive style Mat.: CK45, casted Mat.: CK45, gegossen TH 900 ✎TH 900 / 090 l 065 090 120 150 180 250 300 350 * * Vorbohrung für Zylinderstift Platinen-Einweiser immer in eine Nut einsetzen. * Pilot hole for dowel pin Always place pilot gage into groove. MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [28] [23.02.2023] Platinen-Einweiser, induktiv gehärtet Pilot gages, inductively hardened Mat.: CK45, casted inductively hardened Hardness: 50 - 55 HRC Mat.: CK45, gegossen induktiv gehärtet Härte: 50 - 55 HRC TH 900 … CH ✎TH 900 / 065 / CH l 065 090 120 150 180 250 300 350 * Oberfläche gehärtet / Surface hardened Oberfläche gehärtet / Surface hardened * Vorbohrung für Zylinderstift Platinen-Einweiser immer in eine Nut einsetzen. * Pilot hole for dowel pin Always place pilot gage into groove. MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [29] [23.02.2023] Platinen-Einweiser mit Teillagekontrolle, induktiv gehärtet Pilot gages with part position control, inductively hardened Mat.: CK45, casted inductively hardened Hardness: 50 - 55 HRC Mat.: CK45, gegossen induktiv gehärtet Härte: 50 - 55 HRC TH 901 ✎TH 901 / 150 l l1 l2 a 120 56 70 120 150 56 70 120 180 107 120 124 250 107 120 124 * Vorbohrung für Zylinderstift Platinen-Einweiser immer in eine Nut einsetzen. * Oberfläche gehärtet / Surface hardened Feder / Spring Oberfläche gehärtet / Surface hardened * Pilot hole for dowel pin Always place pilot gage into groove. MAIL

[16.07.2021] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [30] TH 39D 639 ✎TH 39D 639 / 40 Lagekontrolle für Platinen Position Control for Blanks  Teil 14 Mat.: S235  Teil 19 Mat.: 1.4021 Härte: 40-45 HRC  Teil 25 nach DIN 2098  Teil 24 nach DIN 934  Teil 23 M6x12 nach ISO 4762  Teil 26, Ø4x14 nach DIN 7337 Mat.: Alu/Stahl  Piece 14 Mat.: S235  Piece 19 Mat.: 1.4021 Hardness: 40-45 HRC  Piece 25 acc. DIN 2098  Piece 24 acc. DIN 934  Piece 23, M6x12 acc. ISO 4762  Piece 26, Ø4x14 acc. DIN 7337 Mat.: Alu/steel Typ / Type l l1 40 145 87 41 185 127 42 225 167 21 38 l1 l -oilless.com info@gsb-oilless.com 3.122 CODE I1 l M301-15-145 87 145 M301-15-185 127 185 M301-15-225 167 225 rial : rial : 1 ened 40-45 rial : g DIN 2098 rial : IN 934 rial : w M6x12 ISO 4762 rial : Ø4x14 DIN 7337 5 6 2 3 1 l1 l 21 80 38 86 60 R4,2 30 4 80 30 60 86 R4,2 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [31] [23.02.2023] Zentriereinheiten mit Distanzscheibe Tapered interlocks with spacer disk Mat.: 16MnCr5, hardened Surface hardness: 60 - 64 HRC Mat.: 16MnCr5, gehärtet Randschichthärte: 60 - 64 HRC TH 920 ✎TH 920 / A x 100 Form d d1 d2 d3 l l2 t A 100 76 58 40,5 80 55 10,5 B 100 76 58 40,5 80 55 10,5 A 120 96 78 50,5 90 65 10,5 B 120 96 78 50,5 90 65 10,5 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [32] [23.02.2023] Zentrierbolzen Locating pins Mat.: 16MnCr5, hardened Surface hardness: 60 - 64 HRC Mat.: 16MnCr5, hardened Surface hardness: 60 - 64 HRC Mat.: 16MnCr5, gehärtet Randschichthärte: 60 - 64 HRC Mat.: 16MnCr5, gehärtet Randschichthärte: 60 - 64 HRC TH 943 TH 944 ✎ ✎ TH 943 / 32 x 50 TH 944 / 32 x 50 d l d1 +0,2 l1 l2 M r t 22 45 14 37,5 8 M10 12,5 25 32 50 18 40 10 M12 20 35 40 55 18 40 10 M12 20 35 50 55 18 40 10 M12 20 35 d1 h6 l1 +0,2 d2 -0,05 l2 +0,2 l3 +0,2 M r +0,2 22 45 22 16 35 M8 15 22 55 22 16 45 M8 15 32 50 32 20 37,5 M10 20 40 55 40 20 35 M10 25 40 65 40 20 45 M10 25 40 85 40 20 65 M10 25 50 55 50 20 41,25 M10 25 56 80 56 20 60 M10 30 d -0,05 -0,1 d j6 MAIL MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [33] [23.02.2023] Tragschrauben, VDI 3366 Lifting pins, VDI 3366 Mat.: CK45 Tensile strength: 700 - 800 N/mm2 Mat.: CK45 Zugfestigkeit: 700 - 800 N/mm2 TH 230 ✎TH 230 / 20 d ±0,1 Tragfähigkeit Lifting capacity [N] d1 a b ±0,5 f k l1 ±1 r1 r2 s 16 2500 M16 20 28 3 5 58 5 8 24 20 5000 M20 22 34 3 6 68 5 8 30 25 10000 M24 25 38 4 8 78 6 10 36 32 15000 M30 32 45 5 10 95 6 10 41 40 25000 M36 40 56 5 12 118 8 12 50 MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [34] [23.02.2023] Tragzapfen, VDI 3366 Lifting brackets, VDI 3366 Mat.: CK45 Tensile strength: 700 - 800 N/mm2 Mat.: CK45 Zugfestigkeit: 700 - 800 N/mm2 TH 220 ✎TH 220 / 20 d1 ±0,1 Tragfähigkeit Lifting capacity [N] Form f h l1 l2 l3 l4 l5 • DIN 912 min. 8.8 16 3200 A 20 6 80 6 20 10 44 M8 x 25 20 6300 A 25 8 90 8 25 10 47 M10 x 30 25 12500 A 35 10 100 8 30 12 50 M12 x 40 32 20000 A 40 10 120 10 32 16 62 M16 x 45 40 32000 A 50 12 140 10 40 18 72 M20 x 60 50 50000 A 60 14 160 12 45 22 81 M24 x 70 63 80000 B 80 16 200 12 50 20 98 M20 x 90 80 125000 B 100 18 250 15 65 25 125 M24 x 110 100 200000 B 120 20 300 15 80 30 155 M30 x 130 Passung / Seat Passung / Seat f/2 = = MAIL CAD

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [35] [23.02.2023] Tragzapfen mit Seilsicherung, VDI 3366 Lifting brackets with rope stop safety, VDI 3366 Mat.: CK45 Tensile strength: 700 - 800 N/mm2 Mat.: CK45 Zugfestigkeit: 700 - 800 N/mm2 TH 221 ✎TH 221 / 20 d1 Tragfähigkeit Lifting capacity [N] Form d5 f h l1 l2 l3 l4 l5 • DIN 912 min. 8.8 16 3200 A 60 20 6 80 6 20 10 44 M8 x 25 20 6300 A 70 25 8 90 8 25 10 47 M10 x 30 25 12500 A 70 35 10 100 8 30 12 50 M12 x 40 32 20000 A 110 40 10 120 10 32 16 62 M16 x 45 40 32000 A 110 50 12 140 10 40 18 72 M20 x 60 50 50000 A 150 60 14 160 12 45 22 81 M24 x 70 63 80000 B 150 80 16 200 12 50 20 98 M20 x 90 80 125000 B 150 100 18 250 15 65 25 125 M24 x 110 100 200000 B 150 120 20 300 15 80 30 155 M30 x 130 Passung / Seat Passung / Seat f/2 = = MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [36] [23.02.2023] Tragbolzen mit Fallringsicherung, VDI 3366 Lifting pins, VDI 3366 TH 250 ✎TH 250 / 63 d1 H11 Tragfähigkeit Lifting capacity [N] d d2 +1 e1 l1 +1 l2 +1 s1 Mat. 32 32000 40 34 63 175 145 40 CK45 40 50000 50 42 80 225 188 50 CK45 50 80000 60 52 100 273 230 60 CK45 63 125000 75 65 125 347 295 80 CK45 76 315000 95 78 160 422 360 100 42CrMo4 Sicherheitsstift / Security pin MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [37] [23.02.2023] Unterluftbolzen Lower air pins Mat.: CK45 Tensile strength: 800 - 1000 N/mm2 Mat.: CK45 Zugfestigkeit: 800 - 1000 N/mm2 TH 908 ✎TH 908 / 36 x 185 d1 lmax. d2 l2 l3 Tragfähigkeit Lifting capacity [N] 36 360 90 40 65 50000 45 360 100 50 75 70000 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [38] [23.02.2023] Unterluftbolzen Lower air pins Mat.: CK45 Tensile strength: 800 - 1000 N/mm2 Mat.: CK45 Zugfestigkeit: 800 - 1000 N/mm2 TH 909 ✎TH 909 / A x 205 Form lmax. Tragfähigkeit Lifting capacity [N] A 400 80000 B 400 80000 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [39] [23.02.2023] Oberluftbolzen, VDI 3002 Upper air pins, VDI 3002 Mat.: CK45 Tensile strength: 800 - 1000 N/mm2 Mat.: CK45 Zugfestigkeit: 800 - 1000 N/mm2 TH 910 ✎TH 910 / A x 285 Form lmax. Tragfähigkeit Lifting capacity [N] A 360 50000 B 360 50000 C 360 50000 MAIL

[23.02.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [40] Mat.: 1.7227 (42CrMoS4+QT) Max. Load: 80 kN Overall length l frei wählbar. TH 39D 951/21 ✎TH 39D 951/21 x l Unterluftbolzen Lower Air Pins Mat.: 1.7227 (42CrMoS4+QT) Maximallast: 80 kN Gesamtlänge l frei wählbar. 23 35 70 www.gsb-oilless.com info@gsb-oilles 3.123 Material: 1.7227 (42CrMoS4+QT) Ai Unterluftb CODE Max. Load (kN) M304-10-L 80 17-0,2 40-0,2 70 18 20 A 30 l±0,05 2x30° 23 35 70 75 2x45° Ø11 R3 R50 R10 R3 R50 0,02 A Ø50 Order Example: l= 220 Order Code: M304-10-220 75 R3 R10 20 18 30 70 R50 R50 2x30° l ±0,05 40 -0,2 2x45° R3 Ø11 17 -0,2 MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [41] [23.02.2023] Steckbolzen, Form 1, VDI 3365 Pad retainer pins, Form 1, VDI 3365 Mat.: CK45 Tensile strength: 800 - 1000 N/mm2 Mat.: CK45 Zugfestigkeit: 800 - 1000 N/mm2 TH 911 ✎TH 911 / 32 x 122 d1 e8 l Dynamische Belastbarkeit Dynamic load [N] d2 +0,05 l1 l2 l3 r 32 105 5000 29 22 58 25 4 32 122 5000 29 22 75 25 4 40 139 7500 37 32 75 32 5 40 159 7500 37 32 95 32 5 50 167 12500 47 32 95 40 6 50 192 12500 47 32 120 40 6 63 202 25000 60 32 120 50 6 63 237 25000 60 32 155 50 6 r MAIL

Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [42] [23.02.2023] Steckbolzen, Form 2, VDI 3365 Pad retainer pins, Form 2, VDI 3365 Mat.: 42CrMo5 Tensile strength: 800 - 1000 N/mm2 Mat.: 42CrMo5 Zugfestigkeit: 800 - 1000 N/mm2 TH 912 ✎TH 912 / 32 x 147 d1 e8 l Dynamische Belastbarkeit Dynamic load [N] d2 +0,05 l1 l2 l3 r 32 130 5000 29 22 58 25 4 32 147 5000 29 22 75 25 4 40 171 7500 37 32 75 32 5 40 191 7500 37 32 95 32 5 50 207 12500 47 32 95 40 6 50 232 12500 47 32 120 40 6 63 252 25000 60 32 120 50 6 63 287 25000 60 32 155 50 6 r MAIL

[23.03.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [43] TH 39D 630/22 ✎TH 39D630/22 Dämpfungssysteme für Schieber Slider Stop Damping System  Teil 31 Mat.: S355  Teil 32 Mat.: S355  Teil 33 Mat.: S355  Piece 31 Mat.: S355  Piece 32 Mat.: S355  Piece 33 Mat.: S355 Fmax.: 3,75 kN Max. Energy absorbed: 8 J Max. Stroke: 7 mm Fmax.: 3,75 kN Max. Energieabsorbation: 8 J Max. Hub: 7 mm  Teil 34 Mat.: S355  Teil 37  Teil 36  Teil 35  Piece 34 Mat.: S355  Piece 37  Piece 36  Piece 35 82 Ø8,4 4 22 26 4 Ø30 12,5 gsb-oilless.com info@gsb-oilless.com 3.124 M309-07 Kam Stoper Slider Stop Damping System Dämpfungssystem Schieberanschlag CODE Fmax. (Kn) Max. Energy Absorbed (J) Max. Stroke (mm) M309-07-054033 3.75 8 7 1 3 40 7 Ø30 Ø54 Ø8,4 82 65 12,5 F 22 4 4 26 Ø45 5 2 6 7 4 Ø45 7 Ø54 MAIL

[23.02.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [44]  Teil 10 Mat.: S235JR  Teil 15 Mat.: 1.4310  Teil 16 Mat.: S235  Piece 10 Mat.: S235JR  Piece 15 Mat.: 1.4310  Piece 16 Mat.: S235 TH 39D 578/70 ✎TH 39D 578/70 x 65 Abstellrohre mit Klappvorrichtung, 5 mm Pipes with Assembly, 5 mm  Teil 17 Mat.: S235  Teil 18 Mat.: Weich-PVC  Teil 21  Teil 19 Mat.: Alu/Stahl  Piece 17 Mat.: S235  Piece 18 Mat.: Soft PVC  Piece 21  Piece 19 Mat.: Alu/steel l ±0,05 Max. Belastung / Max. Load [kN] 65 235 70 235 75 235 80 235 85 235 90 235 95 235 100 235 105 235 110 235 115 235 120 235 l ±0,05 Max. Belastung / Max. Load [kN] 125 235 130 235 135 235 140 235 145 235 150 235 155 235 160 235 165 235 170 235 175 235 180 235 l ±0,05 Max. Belastung / Max. Load [kN] 185 235 190 235 195 235 200 235 205 235 210 235 215 235 220 235 225 235 230 235 235 235 240 235 l ±0,05 Max. Belastung / Max. Load [kN] 245 235 250 235 260 235 270 235 280 235 290 235 300 235 310 235 320 235 330 235 340 235 350 235 M321 Montajlı Profil G Pipe with Asse Klapprohrkörper mit Baugr CODE l±0,05 Max. Load (kN) M321-02-070065 65 235 M321-02-070070 70 235 M321-02-070075 75 235 M321-02-070080 80 235 M321-02-070085 85 235 M321-02-070090 90 235 M321-02-070095 95 235 M321-02-070100 100 235 M321-02-070105 105 235 M321-02-070110 110 235 M321-02-070115 115 235 M321-02-070120 120 235 M321-02-070125 125 235 M321-02-070130 130 235 M321-02-070135 135 235 M321-02-070140 140 235 M321-02-070145 145 235 CODE l±0,05 Max. Load (kN) M321-02-070185 185 235 M321-02-070190 190 235 M321-02-070195 195 235 M321-02-070200 200 235 M321-02-070205 205 235 M321-02-070210 210 235 M321-02-070215 215 235 M321-02-070220 220 235 M321-02-070225 225 235 M321-02-070230 230 235 M321-02-070235 235 235 M321-02-070240 240 235 M321-02-070245 245 235 M321-02-070250 250 235 M321-02-070260 260 235 M321-02-070270 270 235 M321-02-070280 280 235 Material : S235JR Material : 1.4310 Material : S235/DC01 Material : Soft-PVC Material : M6 DIN 934 Material : Rivet Ø5x14 DIN 7337 1 2 3 4 5 6 7 l 12,5 12,5 12,5 6 17,5 41 30 70 30 Ø5 Ø5 37 16,2 50 5 R4,25 Ø6,1 1 3 4 6 7 2 5 30 6 12,5 12,5 Ø5 41 17,5 37 Ø5 70 30 16,2 50 12,5 l ±0,05 MAIL

[23.03.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [45] M321-03 Montajlı Profil Gövde Pipe with Assembly Klapprohrkörper mit Baugruppe CODE l±0,05 Max. Load (kN) 1-03-080065 65 125 1-03-080070 70 125 1-03-080075 75 125 1-03-080080 80 125 1-03-080085 85 125 1-03-080090 90 125 1-03-080095 95 125 1-03-080100 100 125 1-03-080105 105 125 1-03-080110 110 125 1-03-080115 115 125 1-03-080120 120 125 1-03-080125 125 125 1-03-080130 130 125 1-03-080135 135 125 1-03-080140 140 125 1-03-080145 145 125 1-03-080150 150 125 CODE l±0,05 Max. Load (kN) M321-03-080185 185 125 M321-03-080190 190 125 M321-03-080195 195 125 M321-03-080200 200 125 M321-03-080205 205 125 M321-03-080210 210 125 M321-03-080215 215 125 M321-03-080220 220 125 M321-03-080225 225 125 M321-03-080230 230 125 M321-03-080235 235 125 M321-03-080240 240 125 M321-03-080245 245 125 M321-03-080250 250 125 M321-03-080260 260 125 M321-03-080270 270 125 M321-03-080280 280 125 M321-03-080290 290 125 terial : 35JR terial : 310 terial : 35/DC01 terial : ft-PVC terial : DIN 934 terial : vet Ø5x12 DIN 7337 12,5 16,2 30 70 3 Ø5 50 30 37 41 17,5 12,5 12,5 6 Ø5 l R4,25 Ø6,1 1 3 4 6 7 2 5 TH 39D 578/80 ✎TH 39D 578/80 x 65 Abstellrohre mit Klappvorrichtung, 3 mm Pipes with Assembly, 3 mm l ±0,05 Max. Belastung / Max. Load [kN] 65 125 70 125 75 125 80 125 85 125 90 125 95 125 100 125 105 125 110 125 115 125 120 125 l ±0,05 Max. Belastung / Max. Load [kN] 125 125 130 125 135 125 140 125 145 125 150 125 155 125 160 125 165 125 170 125 175 125 180 125 l ±0,05 Max. Belastung / Max. Load [kN] 185 125 190 125 195 125 200 125 205 125 210 125 215 125 220 125 225 125 230 125 235 125 240 125 l ±0,05 Max. Belastung / Max. Load [kN] 245 125 250 125 260 125 270 125 280 125 290 125 300 125 310 125 320 125 330 125 340 125 350 125 M Montajlı Prof Pipe with A Klapprohrkörper mit Ba CODE l±0,05 Max. Load (kN) M321-02-070065 65 235 M321-02-070070 70 235 M321-02-070075 75 235 M321-02-070080 80 235 M321-02-070085 85 235 M321-02-070090 90 235 M321-02-070095 95 235 M321-02-070100 100 235 M321-02-070105 105 235 M321-02-070110 110 235 M321-02-070115 115 235 M321-02-070120 120 235 M321-02-070125 125 235 M321-02-070130 130 235 M321-02-070135 135 235 M321-02-070140 140 235 M321-02-070145 145 235 CODE l±0,05 Max. L (kN M321-02-070185 185 23 M321-02-070190 190 23 M321-02-070195 195 23 M321-02-070200 200 23 M321-02-070205 205 23 M321-02-070210 210 23 M321-02-070215 215 23 M321-02-070220 220 23 M321-02-070225 225 23 M321-02-070230 230 23 M321-02-070235 235 23 M321-02-070240 240 23 M321-02-070245 245 23 M321-02-070250 250 23 M321-02-070260 260 23 M321-02-070270 270 23 M321-02-070280 280 23 Material : S235JR Material : 1.4310 Material : S235/DC01 Material : Soft-PVC Material : M6 DIN 934 Material : Rivet Ø5x14 DIN 7 1 2 3 4 5 6 7 l 12,5 12,5 12,5 6 17,5 41 30 70 Ø5 16,2 5 R4,25 Ø6,1 1 3 4 6 7 2 5 30 6 12,5 12,5 Ø5 41 17,5 37 Ø5 3 70 30 16,2 50 12,5 l ±0,05  Teil 11 Mat.: S235JR  Teil 15 Mat.: 1.4310  Teil 16 Mat.: S235  Piece 11 Mat.: S235JR  Piece 15 Mat.: 1.4310  Piece 16 Mat.: S235  Teil 17 Mat.: S235  Teil 18 Mat.: Weich-PVC  Teil 21  Teil 20 Mat.: Alu/Stahl  Piece 17 Mat.: S235  Piece 18 Mat.: Soft PVC  Piece 21  Piece 20 Mat.: Alu/steel MAIL

[23.02.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [46] Information Information Kennzeichnungsstempel Norm-39V 1079 Seite 47 Prägewerke Norm-39D 991 A Seite 50 Prägewerke Norm-39D 991 B Seite 51 Besondere Merkmale: ● Empfohlener Lieferant für Norm-Prägewerke nach VW-Lieferantenvorschrift 39D 999. ● Vollständiges Sortiment an Aufnahmen nach Norm 39D 647. ● Attraktive Preise. ● Garantiertes Versanddatum für Stempel nach 39V 1079 innerhalb von 7 Arbeitstagen (max. 1.000 Stück). Numbering heads Standard-39D 991 A Page 50 Numbering heads Standard-39D 991 B Page 51 Special features: ● Recommended supplier for standard numbering heads according to VW specification 39D 999. ● Complete range of retainers as per VW - standard 39D 647. ● Competitive pricing. ● Guaranteed shipping-time of max 7 days for Identification Punches according to 39V 1079 (up to 1.000 pieces). Aufnahmen für Kennzeichnungsstempel Norm-39D 647 Ausführung 12/13 Seite 48 Ausführung 21-26 Seite 48 Ausführung 30-39 Seite 49 Retainers for identification punches Standard-39D 647 Model 12/13 Page 48 Model 21-26 Page 48 Model 30-39 Page 49 Identification punches Standard-39V 1079 Page 47

[23.03.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [47] Mat.: 1.2379 Hardness: 60+2 HRC Mirror-invented and raised lettering, DIN medium. Laser marking VW part-ident-No. TH 39V 1079 ✎TH 39V 1079 / 20 Kennzeichnungsstempel Norm-39V 1079 Identification punches Standard-39V 1079 Mat.: 1.2379 Härte: 60+2 HRC Schrift spiegelbildlich und erhaben, DIN mittel. Laserbeschriftung VW-Teil-Nr. Ausführung / Model Gravur / Engraving h b2 b3 t VW-Teile-Nr. / VW part-ident-No. 20 0 2 10 6 0,3 39V 1079/20 21 1 2 10 6 0,3 39V 1079/21 22 2 2 10 6 0,3 39V 1079/22 23 3 2 10 6 0,3 39V 1079/23 24 4 2 10 6 0,3 39V 1079/24 25 5 2 10 6 0,3 39V 1079/25 26 6 / 9 2 10 6 0,3 39V 1079/26 27 7 2 10 6 0,3 39V 1079/27 28 8 2 10 6 0,3 39V 1079/28 29 Leerstelle / blank 2 10 6 0,3 39V 1079/29 29 . A - Z 2 10 6 0,3 39V 1079/29A 29 . Sonderzeichen / special character 2 10 6 0,3 39V 1079/29+ 50 0 3,5 13 8 0,4 39V 1079/50 51 1 3,5 13 8 0,4 39V 1079/51 52 2 3,5 13 8 0,4 39V 1079/52 53 3 3,5 13 8 0,4 39V 1079/53 54 4 3,5 13 8 0,4 39V 1079/54 55 5 3,5 13 8 0,4 39V 1079/55 56 6 / 9 3,5 13 8 0,4 39V 1079/56 57 7 3,5 13 8 0,4 39V 1079/57 58 8 3,5 13 8 0,4 39V 1079/58 59 Leerstelle / blank 3,5 13 8 0,4 39V 1079/59 59 . A - Z 3,5 13 8 0,4 39V 1079/59A 59 . Sonderzeichen / special character 3,5 13 8 0,4 39V 1079/59+ t 4 -0,05 4 -0,02 Rz 25 Rz 25 25 -0,05 b3 -0,05 24 b2 -0,1 h 15° 10° MAIL

[23.02.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [48] Mat.: 1.2842 / Pad: PA6G Shim hardened 58+2 HRC incl. shim and pad Laser marking VW part-ident-No. TH 39D 647 ✎TH 39D 647 / 12 Aufnahmen für Kennzeichnungsstempel Norm-39D 647 Retainers for identification punches Standard-39D 647 Mat.: 1.2842 / Polster: PA6G Abstimmplatte gehärtet auf 58+2 HRC inkl. Abstimmplatte und Polster Laserbeschriftung VW-Teil-Nr. Ausführung / Model für Schrifthöhe / for font height [mm] b1 VW-Teile-Nr. / VW part-ident-No. 12 3,5 8,1 39D 647/12 13 2 6,1 39D 647/13 Ausführung / Model für Schrifthöhe / for font height [mm] L1 L2 L3 b1 VW-Teile-Nr. / VW part-ident-No. 21 3,5 9 24 8,1 8,1 39D 647/21 22 3,5 11 28 8,1 8,1 39D 647/22 23 3,5 13 32 8,1 8,1 39D 647/23 24 2 9 24 6,1 6,1 39D 647/24 25 2 11 28 6,1 6,1 39D 647/25 26 2 13 32 6,1 6,1 39D 647/26 Abdrückgewinde / Forcing thread R 0,2 8,1 +0,2 6,5 b1 +0,2 Ø11 M8 -0,05 Ø25 -0,30 20,6 -0,1 18 +0,2 30 Abdrückgewinde / Forcing thread R 0,2 L3 +0,2 L2 d9 b1 +0,2 13 d9 L1 ±0,1 Ø11 M8 20,6 -0,1 18 +0,2 30 Ausführungen 12,13 / Models 12,13 Ausführungen 21 - 26 / Models 21 - 26 MAIL

[23.03.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [49] Mat.: 1.2842 / Pad: PA6G Shim hardened 58+2 HRC incl. shim and pad Laser marking VW part-ident-No. TH 39D 647 ✎TH 39D 647 / 30 Aufnahmen für Kennzeichnungsstempel Norm-39D 647 Retainers for identification punches Standard-39D 647 Mat.: 1.2842 / Polster: PA6G Abstimmplatte gehärtet auf 58+2 HRC inkl. Abstimmplatte und Polster Laserbeschriftung VW-Teil-Nr. Abdrückgewinde / Forcing thread R 0,2 L3 +0,2 L2 d9 b1 +0,2 13 d9 L1 ±0,1 Ø11 M8 20,6 -0,1 18 +0,2 30 Ausführung / Model für Schrifthöhe / for font height [mm] Anzahl Stempel Number of punches L1 L2 L3 b1 VW-Teile-Nr. / VW part-ident-No. 30 3,5 4 30 43 16,1 8,1 39D 647/30 31 3,5 5 34 47 20,1 8,1 39D 647/31 32 3,5 6 38 51 24,1 8,1 39D 647/32 33 3,5 10 54 67 40,1 8,1 39D 647/33 38 3,5 11 58 71 44,1 8,1 39D 647/38 34 2 4 30 43 16,1 6,1 39D 647/34 35 2 5 34 47 20,1 6,1 39D 647/35 36 2 6 38 51 24,1 6,1 39D 647/36 37 2 10 54 67 40,1 6,1 39D 647/37 39 2 11 58 71 44,1 6,1 39D 647/39 MAIL

[23.02.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [50] Mat.: 1.2842 Hardness: 58+2 HRC incl. shim Laser marking VW part-ident-No. TH 39D 991 A ✎TH 39D 991 A / 01 Prägewerke Norm-39D 991 A Numbering heads Standard-39D 991 A Mat.: 1.2842 Härte: 58+2 HRC inkl. Abstimmplatte Laserbeschriftung VW-Teil-Nr. Ausführung / Model Anzahl Prägeräder / Nummber of wheels Schrifthöhe / Character size [mm] b b1 VW-Teile-Nr. / VW part-ident-No. 01 3 4 40 28 39D 991/01 02 4 4 40 28 39D 991/02 03 5 4 44 32 39D 991/03 04 3 2,5 40 28 39D 991/04 05 4 2,5 40 28 39D 991/05 06 5 2,5 44 32 39D 991/06 b1 39 3,7 51,5 61,2 0,5 17,5 7 b 2x Schrauben DIN EN ISO 4762 M6x60 / 2x screws DIN EN ISO 4762 M6x60 Abstimmplatte / Shim MAIL

[23.03.2023] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM [51] Made by Mat.: 42CrMo4 Mat.: 42CrMo4 TH 39D 991 B ✎TH 39D 991 B / 10 Prägewerke Norm-39D 991 B Numbering heads Standard-39D 991 B Ausführung / Model Anzahl Prägeräder / Nummber of wheels B D VW-Teile-Nr. / VW part-ident-No. 10 4 36 22 39D 991/10 11 6 42 28 39D 991/11 28 B M6 DIN912 D 42 Kantenbruch/Chamfer 4x4 A (Anzahl Ringe/Number of rings) 34.1 Maximale Taschentiefe/ max. cavity depth Mat. 1.2510 Mat. 1.2550 gehärtet/hardened 56-58 HRC 3.8 0.5 15 33.8 Mat.: 1.2379 Hardness: 56 - 59 HRC Mat.: 1.2379 Härte: 56 - 59 HRC TH 927 ✎TH 927 Ziffern 0 bis 9 und 1 x leer Characters 0 to 9 plus one blank 13.8 0.5 3.8 ø24 2.5 2.975±0.1 Prägewerk-Ringe für TH 39D 991 B Numbering head rings for TH 39D 991 B MAIL MAIL

[23.02.2023] [52] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM Pneumatik-Federn Pneumatic springs AZOL GAS Pneumatik-Federn können als Alternative zu Schrauben-, Gasdruck- oder Urethanfedern in Werkzeugen, Vorrichtungen oder Pressen eingebaut werden. Sie werden in metrischen und zölligen Abmessungen angeboten. Vorteile: • Kompakte Bauweise • Hohe Anfangskraft bei geringem Druckanstieg • Lange Lebensdauer (Hohe Stückzahlen) • Minimale Wartung • Keine Ermüdung • Niedrige Kosten durch Anschluss an ein vorhandenes Druckluftsystem Hinweise: Die Pneumatik-Federn werden über das Regulierventil VA8 an das betriebliche Druckluftnetz angeschlossen. Um das Eindringen von Feuchtigkeit aus dem Druckluftnetz in die Feder zu verhindern, muss ein Feuchtigkeits-Abscheider installiert werden. (Feuchtigkeit minimiert den Druckraum, erhöht somit den Druck und kann die Feder zerstören.) Arbeitsweise: Durch Einfahren der Kolbenstange wird die in der Pneumatik-Feder vorhandene Luft komprimiert und der Druck erhöht. Das angebaute Regulierventil verhindert den Rückfluss der Luft aus der Feder in das Druckluftnetz. Werden Netz und Feder getrennt, öffnet das Regulierventil und die Pneumatik-Feder ist drucklos. Achtung: Der Betrieb der Pneumatik-Feder ist nur mit einem Regulierventil erlaubt. AZOL GAS pneumatic springs can be used as alternatives for die springs, gas springs and urethan springs in dies, fixtures and presses. They are available in metric and inch dimensions. Advantages: • Compact design • High initial force at low pressure-increase • Long lifetime (high press-part quantities) • Less maintenance • No „fatigue“ • Low cost due to installation at local air-pressure system Note: The valve-adapter VA8 connects the pneumatic springs with the local air-pressure system. To avoid penetration of moisture into the spring (this reduces space for air, increases internal pressure and eventually destroys the spring), a corresponding de-moisturizer must be installed. Function: The down-movement of the rod increases the internal pressure. The control-valve prevents the air from going back into the local air-pressure system. If system and spring are separated, the valve opens and the spring does not hold pressure any more. Attention: The pneumatic spring must only be used with a control valve.

[23.02.2023] [53] Märkische Stanz-Partner AUTOMOTIVE PROGRAMM / AUTOMOTIVE PROGRAM G 3/8" B1 B LG L1 L H ø 60 M8 15 ø 95 ø 14 16 Pneumatik-Federn, zöllig Pneumatic springs, inch-standard Attention: The pneumatic spring must only be used with a control valve. Specifications: Pressure medium: Air Max. charging pressure: 8,5 bar Min. charging pressure: 2 bar Operating temperature: 0 - 80 °C Max. piston rod speed: 1,5 m/s Achtung: Die Pneumatik-Federn dürfen nur in Betrieb genommen werden, wenn diese mit einem Regulierventil bestückt sind. Technische Daten: Medium: Luft Max. Fülldruck: 8,5 bar Min. Fülldruck: 2 bar Arbeitstemperatur: 0 - 80 °C Max. Kolbengeschw.: 1,5 m/s ✎AZ-VW 110. 00080.012,7 AZ-VW 110.00080 H Hub / Stroke L ±0,25 LG +0,2 L1  B  B1 012,7 111,3 98,6 19,1 114 87,4 025,4 136,7 111,3 19,1 114 87,4 038,1 162,1 124,0 19,1 114 87,4 050,8 187,5 136,7 19,1 114 87,4 063,5 212,9 149,4 19,1 114 87,4 076,2 238,3 162,1 19,1 114 87,4 088,9 263,7 174,8 19,1 114 87,4 101,6 289,1 187,5 19,1 114 87,4 114,3 314,5 200,2 19,1 114 87,4 127,0 339,9 212,9 19,1 114 87,4 139,7 365,3 225,6 19,1 114 87,4 152,4 390,7 238,3 19,1 114 87,4 Druckanstiegsfaktor / Multiplier coeficient Hub / Stroke [mm] Genutzter Hub / Used stroke x1 x4 x2 x3 x1.5 x2.5 x3.5 x4.5 1 13 25 37 49 61 73 97 109 121 133 145 157 85 12.7 25.4 38.1 50.8 63.5 76.2 88.9 127 101.6 139.7 114.3 152.4 MAIL
